| Optical Design: |
Schmidt-Cassegrain |
| Aperture: |
203.2mm (8") |
| Focal Length: |
2032mm (80") |
| Focal Ratio: |
f/10 |
| Focal Length of Eyepiece 1: |
40mm (1.57") |
| Magnification of Eyepiece 1: |
51x |
| Focal Length of Eyepiece 2: |
13mm (.51") |
| Magnification of Eyepiece 2: |
156x |
| Finderscope: |
Red Dot Finderscope |
| Star Diagonal: |
1.25" Star Diagonal |
| Optical Tube: |
Aluminum |
| Highest Useful Magnification: |
480x |
| Lowest Useful Magnification: |
29x |
| Limiting Stellar Magnitude: |
14 |
| Resolution (Rayleigh): |
0.69 arc seconds |
| Resolution (Dawes): |
0.57 arc seconds |
| Light Gathering Power (Compared to human eye): |
843x |
| Secondary Mirror Obstruction: |
64mm (2.5") |
| Secondary Mirror Obstruction by Diameter: |
31% |
| Secondary Mirror Obstruction by Area: |
9.77% |
| Optical Coatings: |
StarBright XLT |
| Optical Tube Length: |
432mm (17") |
| Optical Tube Diameter: |
238mm (9.37") |
| Optical Tube Weight: |
12.5 lbs (5.67 kg) |
| Dovetail: |
CG-5 Dovetail bar |
| Mount Type: |
Computerized Altitude-Azimuth Single Fork Arm |
| Instrument load capacity: |
25 lbs (11 kg) |
| Height adjustment range (includes mount and tripod): |
1193.8mm - 1752.6mm (47" – 69") |
| Tripod Leg Diameter: |
38.1mm (1.5") Stainless Steel |
| Mount Head Weight: |
16 lbs (7 kg) |
| Accessory Tray: |
Yes |
| Tripod Weight: |
12 lbs (5.44 kg) |
| Slew Speeds: |
9 slew speeds - max speed 4°/second |
| Tracking Rates: |
Sidereal, Solar and Lunar |
| Tracking Modes: |
Alt-Az, EQ North and EQ South |
| GPS: |
N/A |
| Dovetail Compatibility: |
CG-5 saddle plate |
| Number of Auxiliary Ports: |
4 AUX Ports (Hand Control can use any of the AUX Ports) |
| Autoguide Port: |
No |
| USB Port: |
Yes, Hand Control input and Mount output |
| Power Requirements: |
Internal 9 6V, 4 5Ah lithium iron phosphate battery (LiFePO4) |
| Motor Drive: |
DC servo motors |
| Alignment Procedures: |
SkyAlign, 1-Star Align, 2-Star Align, Auto 2-Star Align, Solar System Align, Quick-Align, Last Alignment, EQ North / EQ South Alignment (EQ align requires an equatorial wedge) |
| Periodic Error Correction: |
No |
| Computerized Hand Control: |
2 line x 18 character backlit Liquid Crystal Display, 19 LED backlit buttons, USB 2.0 Port for PC connection |
| NexStar+ Database: |
Over 40,000 including 220 of the best deep sky and solar system objects |
| Software: |
Celestron Starry Night Special Edition Software and SkyPortal App |
| Total Kit Weight: |
40.5 lbs (18.37 kg) |
| Included Items: |
Optical tube
Single Fork Arm Mount and Tripod
Accessory Tray
Built-in Wifi
Integrated Lithium-iron battery
NexStar+ Hand Control
40mm and 13mm eyepiece
Red dot finderscope
Visual Back
Star Diagonal
4 plug AC adapter |
| Solar Warning |
- Never look directly at the Sun with the naked eye or with an optic (unless you have the proper solar filter). Permanent and irreversible eye damage may result.
- Never use your optic to project an image of the Sun onto any surface. Internal heat build-up can damage the optic and any accessories attached to it.
- Never leave your optic unsupervised. Make sure an adult who is familiar with the correct operating procedures is with your optic at all times, especially when children are present.
|
