| Magnification: |
8x |
| Objective Lens Diameter: |
21mm (.82") |
| Angular Field of View: |
7.4° |
| Linear Field of View (@1000 yds) / @1000 m): |
378 ft (129 m) |
| Exit Pupil: |
2.6mm (.1") |
| Eye Relief: |
11mm (.43") |
| Close Focus: |
10 ft (3 m) |
| Interpupillary Distance (max): |
72mm (2.83") |
| Interpupillary Distance (min): |
58mm (2.28") |
| Diopter Adjustment Range: |
±2 |
| Twilight Factor: |
12.96 |
| Relative Brightness: |
6.76 |
| Limiting Stellar Magnitude: |
Ideal: 9.11
Moderate: 8.11
Poor: 7.11 |
| Lens Coatings: |
Multi-Coated |
| Prism Glass (Type): |
Bk7 |
| Prism Coatings: |
N/A |
| Weight: |
8 oz (227 g) |
| Environmental Protection: |
Water Resistant |
| Nitrogen Filled: |
No |
| Tripod Adaptable: |
No |
| Carrying Case: |
padded soft sided cloth |
| Dimensions: |
69mm x 51mm x 91mm (2.7" x 2.0" x 3.6") |
| Included Items: |
Carrying case
Lens cloth
Instruction manual |
| Solar Warning |
- Never look directly at the Sun with the naked eye or with this optic. Permanent and irreversible eye damage may result.
- Never use your optic to project an image of the Sun onto any surface. Internal heat build-up can damage the optic and any accessories attached to it.
- Never leave your optic unsupervised. Make sure an adult who is familiar with the correct operating procedures is with your optic at all times, especially when children are present.
|
