Optec DirectSync SVX35 Motor: Advanced Focusing for Stellarvue 3.5" Focusers

Key Features:

• Precision Engineering for Stellarvue: The DirectSync SVX35 motor is specifically designed for Stellarvue's large 3.5" series focusers, incorporating Optec's innovative ThirdLynx control circuit.

• Best-In-Class Clutch Mechanism: Inherits the acclaimed clutch system from the original DirectSync SV30 motors, ensuring top-tier precision and reliability in focusing.

• Integrated Control Circuit: Features a newly designed control circuit, seamlessly integrated into the focus motor end cap for a streamlined and efficient setup.

• No Need for External Controllers: Simplifies your telescope setup by eliminating the requirement for an external controller, enhancing ease of use.

• USB Connectivity: Fully compatible with USB interfaces, ensuring hassle-free integration with all existing FocusLynx software.

• Wide Telescope Compatibility: Perfectly fits a variety of large Stellarvue telescopes and focusers, including:

  • Stellarvue 3.5-inch focuser.
  • Stellarvue FSV-35 focuser.
  • Notable telescope models like SVX130T, SVX140T, and SVX152T.

Specifications

• Motor Housing Width: 1.9" (48mm)
• Overall Length: 4.55" (115mm)
• Weight: 6.0 oz (165 g)
• Step Resolution: 1.1 micron per step
• Stepper Motor: Bi-polar NPM 15-ohm with 1:25 gearhead
• Controller: Integrated ThirdLynx
• Connectivity: USB 2.0 A-B cable (included)
• Temperature Sensor: Analog Devices ADT7302 embedded
• Input Power: 12-volts DC, 2.5 x 5.5mm plug
• Current Draw: Maximum draw approx. 350mA

Software and Docs

• Flyer
• Installation Instructions
• FocusLynx download page
