ZWO ASI120MM Mini USB2.0 MonoGuide Camera

$149.00

  ZWO ASI120MM Mini USB2.0 Mono Guide Camera Advanced Sensor: Features the AR0130CS 1/3" sensor (4.8 mm x 3.6 mm), offering 1280 x 960 resolution with each pixel measuring 3.75 μm...

Add to Wishlist

amazon paymentsamerican expressapple paybitcoingoogle payjcbmasterpaypalshopify paysofortvisa
Ask a Question
SKU: ASI120MINI
Availability: In Stock Pre order Out of stock
Categories: Astrophotography Cameras ZWO ZWO ZWO Imagers
Tags: 120 Camera Mini Mono ZWO
Description



ZWO ASI120MM Mini USB2.0 Mono Guide Camera

  • Advanced Sensor: Features the AR0130CS 1/3" sensor (4.8 mm x 3.6 mm), offering 1280 x 960 resolution with each pixel measuring 3.75 μm x 3.75 μm.
  • High-Quality Imaging: Delivers a high quantum efficiency (QE) peak of nearly 80% with a 12-bit ADC, ensuring detailed and clear images.
  • Astrophotography Optimized: Ideal for planetary imaging and guiding, boasting low read noise and a high dynamic range. Includes an AR protective window for enhanced performance.
  • Connectivity Options:
    • USB 2.0 Type-C Port: Simplifies connections with its reversible plug design. Compatible with most modern mobile phones. Requires a USB-C to USB-A cable.
    • ST4 Port: Allows direct connection to the auto-guider port of your telescope mount for precise tracking and guiding during astrophotography sessions.

This compact and efficient guide camera from ZWO is part of their "mini" series, offering excellent functionality for both beginners and experienced astrophotographers seeking a reliable guiding solution or a dedicated camera for planetary imaging.

Specifications

Feature Specification
Sensor 1/3″ CMOS AR0130CS (Mono)
Resolution 1.2 Mega Pixels, 1280×960
Pixel Size 3.75µm
Exposure Range 64µs-2000s
ROI (Region of Interest) Supported
Non-volatile Memory Build-in 192K byte user-accessible (image size up to 480x320)
ST4 Guider Port Yes
Focus Distance to Sensor 8.5mm
Shutter Type Rolling Shutter
Protect Window AR coated window
Operating System Compatibility Mac, Windows, Linux
Interface USB2.0
Bit Rate 12bit output
Adaptor 1.25″ / M28.5X0.6
Dimension φ36mm X 61mm
Weight 60g or 3.1 ounces (without lens)
Working Temperature -5°C—45°C
Storage Temperature -20°C—60°C
Working Relative Humidity 20%—80%
Storage Relative Humidity 20%—95%
Supported Resolution (Binning 1x1) 1280x960@35FPS; 1280x720@46FPS; 1024x768@54FPS; 800x600@90FPS; 640x480@118FPS; 320x240@224FPS
Supported Resolution (Binning 2x2) 640x480@35FPS
